2-1/16-Inch Stepper-Motor Oil Pressure Gauge (0-100 PSI) by AutoMeter®
Remote pressure sender keeps oil outside the cabin and supports a 0.5-4.5V data output.
This 2-1/16-inch AutoMeter® oil-pressure gauge combines an analog 0-100-PSI dial with a digital stepper motor and automatic calibration at startup. The stainless steel pressure sender mounts at the engine, so an electrical signal rather than an oil line runs to the gauge. A 0.5-4.5-volt output can feed compatible data-acquisition equipment. The package includes a 1/8-inch NPT pressure sender, wiring harness, mounting hardware and instructions, with 1/4-, 3/8- and 1/2-inch NPT adapters for the oil-pressure port. It operates on 12- or 16-volt electrical systems. Select the gauge series to match the other instruments; lighting and face colors vary by series.
• 2-1/16-inch gauge; 0-100 PSI
• Stepper-motor movement with startup calibration
• Stainless steel 1/8-inch NPT sender included
• Electrical sender connection keeps oil out of the cabin
• 0.5-4.5V output for compatible data logging
• 1/4-, 3/8- and 1/2-inch NPT sender adapters
• Wiring harness, mounting hardware and instructions included
• 12- and 16-volt compatible
Notes
- Part# C210377, "Extended Mounting Base", is for mounting "Sport-Comp", "Phantom", "Ultra-Lite" and "Pro-Comp" tachs and gauges in cups on the dashboard.
- This item is not eligible for any further discounts or promotional pricing.
