1-1/2-Inch Midnight Silver Liquid-Filled Vacuum Gauge by Marshall Instruments™
Silicone filling steadies the vacuum reading; the rear port connects directly to the vacuum source.
This 1-1/2-inch Marshall Instruments™ gauge measures vacuum rather than positive system pressure. Silicone filling damps pointer vibration; the stainless steel case, brass internals and clear acrylic lens protect the mechanical movement. The Midnight Silver dial uses a red pointer and a chrome-finished case and bezel. A 1/8-inch NPT center-back connection mounts at the vacuum source. The case is 1.6 inches in diameter with a 1.75-inch bezel. The measuring range is 0-30 inches Hg of vacuum.
• 1-1/2-inch mechanical vacuum gauge
• 0-30 inches Hg vacuum range
• Midnight Silver dial with red pointer
• Silicone-filled vibration damping
• Chrome-finished case and bezel
• 1/8-inch NPT center-back connection
• Stainless steel case, brass internals and acrylic lens
• 1.6-inch case; 1.75-inch bezel
