1970-72 Buick Skylark VFD Digital Instrument System by Dakota Digital®
Six-gauge VFD system adds complete digital instrumentation with oil, water and speed senders.
Convert your 1970-72 Buick Skylark to Dakota Digital Series III VFD instrumentation. Dakota Digital's Series III VFD system provides six high-brightness vacuum-fluorescent digital readings: 0-255 MPH speedometer, 0-17,500 RPM tachometer, 0-99 psi oil pressure, 0-300°F water temperature, 0-99% fuel level and 8-17 VDC voltage. Its message-center functions include a one-time-settable million-mile odometer, dual trip meters, 0-60 mph and quarter-mile timers, trap-speed data, high-speed recall and high-RPM recall. Built-in indicator support includes turn signals, high beam, check engine, parking brake, cruise and optional gear position when used with the GSS-3000. The included sender package supplies 1/8-inch NPT water-temperature and solid-state oil-pressure sensors, a GM-style cable-driven speed pulse generator with 10-foot harnesses, plus common NPT/metric adapter bushings. Pushbutton programming handles speedometer, cylinder-count and fuel-level calibration. Blue or Teal VFD display configurations are available. Dakota Digital lists VFD3-70B-SKY specifically for 1970-72 Buick Skylark applications. The system is designed around the original dash architecture and delivers a complete six-gauge digital package with programmable vehicle setup and performance functions. Current black-plastic VFD control boxes also support BIM expansion modules for additional data channels.
• Dakota fitment: 1970-72 Buick Skylark
• Six high-brightness VFD digital gauge readings
• 0-255 MPH speedometer and 0-17,500 RPM tachometer
• Includes oil-pressure, water-temperature and speed senders
• Odometer, dual trip and performance functions
• Blue or Teal VFD display configurations
