Crate Engine, BluePrint 540ci ProSeries Stroker, Long Block, Power Adder Ready

540ci Pro Series Power-Adder Long Block by BluePrint Engines®

615-hp / 579 lb-ft core uses forged 4.25-inch crank and forged pistons by BluePrint Engines®.

BluePrint Engines®' 540ci Pro Series Power-Adder Long Block is rated at 615 hp and 579 lb-ft with 8.5:1 compression. It combines forged 4.25-inch-stroke crankshaft, forged pistons, 119cc aluminum heads and solid-roller camshaft (.652/.652 lift; 255/262° @ .050, 114° LSA). 8.5:1 compression, forged rotating assembly and solid-roller cam make this 540 a power-adder-oriented long block.

Additional Technical Specifications • HP & Torque: 600 HP / 590 FT LBS • Compression Ratio: 8.5:1 Block: • NEW BluePrint Cast Iron Block • Manufactured and Machined in the USA! • 4-Bolt Main • 4.500" Bore • 1-Piece Rear Main Seal • Mech fuel pump provision: Yes • Standard Deck Rotating Assembly: • 4.250" Stroke, Dual Keyway • Forged H-beam 6.385" connecting rods Cylinder Heads: • BluePrint Aluminum Cylinder Heads • 119cc chamber • 2.30" intake/1.88" exhaust valves • 316cc intake/124cc exhaust runners • Cylinder heads feature a .300 in. raised exhaust port vs an OEM casting. • Must verify header/exhaust clearance Cam Specs: • .652 Intake .652 Exhaust • 255 Intake / 262 Exhaust duration • @ .050 - 114-degree lobe separation Ignition Timing: • Initial timing - 10-16° and Total timing 32-34° Also Includes: • Valve covers, oil pan and timing cover • Roller Rockers with Stud Girdles • SFI Rated Dual Keyway 8 in. Balancer Notes: • Built to accept Power Adders • Crank machined for dual keyway damper. • New BluePrint block manufactured and machined in the USA. • Not for EGR • Cylinder heads feature a .300 in. raised exhaust port vs an OEM casting
