1974 Chevelle/El Camino Complete Chassis Wiring Diagram Manual
Licensed GM wiring-diagram reproduction includes lighting, dash, engine, A/C and tachometer circuits.
This licensed GM wiring-diagram reproduction covers 1974 Chevelle/El Camino. It includes specifications for interior and exterior lighting, dash wiring, engine harnesses, forward-lamp circuits, A/C and tachometer wiring.
• Covers 1974 Chevelle/El Camino
• Licensed GM reproduction of original factory wiring diagrams
• Interior and exterior lighting circuits
• Dash, engine-harness and forward-lamp wiring
• Includes A/C and tachometer wiring
