1962 Tempest Color Wiring Diagram, 11 x 17 Inches
Laminated, color-coded wiring layout with factory wire colors and tracer markings.
Color-coded circuits help you follow the original wiring layout from the dashboard through the vehicle. This laminated 1962 Tempest diagram shows factory wire colors, including tracer markings, so you can compare the diagram with the harness while tracing connections and electrical faults. The 11 x 17-inch format keeps the circuit layout easy to consult at the workbench. Covers the base vehicle wiring; optional-equipment coverage is not implied.
• Factory wire colors and tracer markings
• Laminated diagram for workshop handling
• Diagram size: 11 x 17 inches
• Vehicle wiring connections and circuit tracing
