Edelbrock Manifold/Carb Kit, Small Block, Perf Air Gap/Thunder 800 Carb

Intake Manifold & Carburetor Kit, 1957–86 Small-Block Chevy, RPM Air-Gap, 800 CFM, Edelbrock

RPM Air-Gap intake manifold and 800 CFM AVS2 carburetor kit for small-block Chevy V8 engines.

Enhance the performance of your small-block Chevrolet V8 with this Edelbrock Performer RPM Air-Gap intake manifold and carburetor kit. Designed for compatible 1957–86 Chevrolet small-block engines, this package combines the Performer RPM Air-Gap #7501 aluminum intake manifold with an 800 CFM AVS2 four-barrel carburetor. The dual-plane manifold features an open-air space beneath the runners that separates the intake runners from hot engine oil in the lifter valley, helping reduce heat transfer to the incoming air/fuel mixture. Its high-rise design is engineered to support strong midrange and upper-RPM performance, making it well suited for performance-oriented street engines. The included Edelbrock AVS2 #1913 carburetor features an electric choke and annular-flow primary boosters designed to improve fuel atomization and throttle response. Both the manifold and carburetor feature a satin finish for a coordinated appearance, while the supplied chrome fuel inlet adds a finishing touch to the installation. The kit also includes an intake manifold gasket set, manifold bolt kit and carburetor mounting studs, providing the primary components needed for a matched induction system. This combination offers a convenient solution for engine upgrades and performance builds without the need to select the manifold, carburetor and installation hardware separately.

Features • Designed for compatible 1957–86 Chevrolet small-block V8 engines • Includes Edelbrock Performer RPM Air-Gap intake manifold #7501 • Dual-plane, high-rise aluminum intake manifold design • Air-gap construction helps reduce heat transfer to the intake runners • Includes Edelbrock AVS2 Series 800 CFM four-barrel carburetor #1913 • Annular-flow primary boosters help improve fuel atomization • Electric choke for convenient cold starting • Satin-finish intake manifold and carburetor • Includes chrome fuel inlet assembly #8126 • Includes intake manifold gasket set #7201 • Includes intake manifold bolt kit #8504 • Includes carburetor stud kit #8008 • Matched intake manifold and carburetor combination • Designed for performance-oriented street applications
