Edelbrock Manifold/Carb Kit, Big Block, Round, Air Gap/Thunder 800 Carb

Intake Manifold & Carburetor Kit, Big-Block Chevy, Rectangular-Port, RPM Air-Gap, 800 CFM, Edelbrock

RPM Air-Gap intake manifold and 800 CFM AVS2 carburetor kit for rectangular-port big-block Chevy V8s.

Increase the performance potential of your big-block Chevrolet V8 with this Edelbrock Performer RPM Air-Gap intake manifold and carburetor kit, designed for compatible 396–502 cubic-inch engines equipped with rectangular-port cylinder heads. This matched induction package combines the Performer RPM Air-Gap #7562 aluminum intake manifold with an 800 CFM AVS2 four-barrel carburetor to promote improved airflow, throttle response and horsepower. The high-rise, dual-plane manifold features an open-air space beneath the intake runners that helps reduce heat transfer from the engine's lifter valley to the incoming air/fuel mixture. Engineered for performance in the 1,500–6,500 RPM range, this combination supports strong midrange torque and upper-RPM power for modified street engines and performance builds. The included AVS2 carburetor features annular-flow primary boosters designed to improve fuel atomization and an electric choke for convenient cold starting. Its air-valve secondary system responds to engine airflow demand, helping provide smooth power delivery throughout the operating range. The satin-finish aluminum manifold and ball-burnished carburetor offer a coordinated appearance, while the included chrome fuel inlet provides a polished finishing touch. An intake manifold gasket set, mounting bolts and carburetor studs are also supplied to simplify installation. Combining these components into one package provides a convenient solution for upgrading compatible rectangular-port Chevrolet big-block engines without sourcing the induction components and essential mounting hardware separately.

Features • Designed for compatible 396–502 cubic-inch big-block Chevrolet V8 engines • Requires rectangular-port cylinder heads • Includes Edelbrock Performer RPM Air-Gap intake manifold #7562 • High-rise, dual-plane aluminum intake manifold construction • Air-gap design helps reduce heat transfer to the intake runners • Designed for performance in the 1,500–6,500 RPM range • Includes Edelbrock AVS2 800 CFM four-barrel carburetor #1913 • Annular-flow primary boosters help improve fuel atomization • Electric choke for convenient cold starting • Air-valve secondary system responds to engine airflow demand • Satin-finish intake manifold and ball-burnished carburetor • Square-bore carburetor mounting configuration • Includes chrome fuel inlet #8126 • Includes intake manifold gasket set #7202 • Includes intake manifold bolt kit #8564 • Includes carburetor mounting stud kit #8008 • Non-EGR intake manifold configuration
