Sending Unit, Fuel, 1988 Cadillac Eldorado & Seville

1988 Cadillac Eldorado & Seville 4.5L Fuel Sending Unit

The 0-175-ohm sender includes the lock ring, seal and strainer for tank installation.

This reproduction fuel sending unit services 1988 Cadillac Eldorado and Seville models with the 4.5L engine. The stainless steel main body and brass float retain the original-style sensing arrangement, and a new neoprene gasket is included. The mapped FG19A sender operates from 0 ohms empty to 175 ohms full and uses a five-pin oval connector. Its lock ring and strainer are included, but the fuel pump and wiring harness are not. Match the resistance range and connector to your original sender before installation.

• 1988 Cadillac Eldorado and Seville 4.5L • 0 ohms empty; 175 ohms full • Five-pin oval electrical connector • Stainless steel body and brass float • Seal, lock ring and strainer included • Fuel pump and harness not included
